SAMEC TS 100A

SAMEC TSS100A Technical dataIn accordance with CE standards Data setup by keyboard and back lighted display Programmable quantity of pieces max. 9.999 Lots programmable Workable length min.45 mm - max.100 mt. Workable diameter min.0,5 mm - max. 9 mm Max cross section (multiconductor stranded cable) 16 mm2 Insulator displaceable length max.20mm Single wire stripping length min.3 mm Total unjacketing length 100 mm x mod.TSS100A - 230 mm x mod. TSS-2TA Feed speed max. 1mt/sec. Connectors for accessories pre- feeder or dereeler,programmed marker,linear stacker or rewinder Power supply-absorption 230 V 50/60 Hz. - 2A Air supply 6-8 bar uninterrupted Overall dimensions and weight TSS100A and TSS100AP 1100x590xH600 mm - Kg.70 Overall dimensions and weight TSS2TA and TSS2TAP 1230x590xH600 mm - Kg.95 TSS100AP and TSS-2TAP the same features with the following variations Storable customer quantity max. 50 Storable cable quantity per customer max.20 Workable length min.45 mm - max.500 mt. Total unjacketing length 100 mm x mod. TSS100AP - 230 mm x mod. TSS2TAP Short end unjacketing length max 110 mt. mod. TSS2TAP Programmable unjacketing length on the opposite side max. 9 mt. mod. TSS2TAP Feed speed with servo-motor assistance max. 2,3 mt/sec. Programmable acceleration and deceleration ramps YES

SAMEC TS 100A
